Standard Equipment

• Coupler: 2 5/16" Forged Adjustable 5/Position
• Jack: 10000# Drop Leg
• Fenders: HD Diamond Plate w/Drop
• Floor: 2" Treated Pine
• Brake: Electric All Wheel
• Break Away Unit w/Charger
• Suspension: Slipper Spring
• DOT Reflective Tape
• Sealed Flush Mount LED Lights
• Stake Pockets
• Spare Rack
• Colors: Refer to Chart

Frame Structure

• Frame: 6" Channel on 16-24'
• Frame: 8" Channel on 26-32'
• Tongue: 6" Channel thru 24'
• Tongue: 8" Channel on 26-32'
• Front Bumper w/Side Gussets
• Crossmembers: 3" Channel 16" OC
• 2' Treadplate Dovetail
• 1/4x2 Rubrail
• Flush Floor w/Floor to Fender Ht. 11" on 6" & 9" on 8" Frame
• Options
  • Spare ST235/80R/16 LRE on 8-Hole
  • Spring Assist on Fold Up Ramps
  • 6' Fold Up Channel Ramps
